Baojing Steel supplies high-quality Duplex Stainless Steel Coils in Lean Duplex, Standard Duplex and Super Duplex grades, including 2101, 2304, 2205, 2507 and S32760.
Duplex stainless steel combines the advantages of austenitic and ferritic stainless steels, offering an excellent balance of high mechanical strength, corrosion resistance, resistance to stress corrosion cracking and good weldability.
Our Duplex Stainless Steel Coils are available in cold rolled and hot rolled conditions, with various surface finishes and customized dimensions. They are widely used in oil & gas, petrochemical, chemical processing, marine, offshore, desalination, pulp & paper, heat exchangers, pressure vessels and industrial piping.
| Item | Specification |
|---|---|
| Product | Duplex Stainless Steel Coil |
| Material Type | Austenitic-Ferritic / Duplex Stainless Steel |
| Main Grades | 2101 / 2304 / 2205 / 2507 / S32760 |
| Grade Family | Lean Duplex / Standard Duplex / Super Duplex |
| Product Forms | Coil / Sheet / Strip / Plate |
| Production Process | Cold Rolled / Hot Rolled |
| Main Standards | ASTM / ASME / EN / JIS / GB/T |
| ASTM Reference | ASTM A240 / A240M |
| ASME Reference | ASME SA240 / SA240M |
| Surface Finish | 2B / BA / No.1 / No.4 / HL / Customized |
| Edge | Mill Edge / Slit Edge |
| Thickness | Customized |
| Width | Customized / Slit Width |
| Coil ID | Customized |
| Coil Weight | Customized |
| Heat Treatment | Solution Annealed |
| Packing | Standard Export Seaworthy Packing |
| Inspection | Mill Inspection / Third-Party Inspection |
| Certificate | EN 10204 3.1 / MTC |
| Applications | Oil & Gas / Marine / Chemical / Offshore / Desalination / Heat Exchanger |
| Category | Grade | UNS | EN | Key Characteristics |
|---|---|---|---|---|
| Lean Duplex | 2101 | S32101 | 1.4162 | High strength, good corrosion resistance, economical nickel content |
| Duplex | 2304 | S32304 | 1.4362 | Good corrosion resistance and high strength |
| Duplex | 2205 | S31803 / S32205 | 1.4462 | Excellent overall corrosion resistance and mechanical strength |
| Super Duplex | 2507 | S32750 | 1.4410 | Very high corrosion resistance and strength |
| Super Duplex | S32760 | S32760 | 1.4501 | Excellent pitting, crevice and stress corrosion resistance |
2205 / S32205 is one of the most widely used duplex grades, while 2507 / S32750 provides higher corrosion resistance and mechanical strength for more aggressive environments.
| Grade | UNS | C Max. | Si Max. | Mn Max. | P Max. | S Max. | Cr % | Ni % | Mo % | N % |
|---|---|---|---|---|---|---|---|---|---|---|
| 2101 | S32101 | 0.040 | 1.00 | 5.00 | 0.040 | 0.030 | 21.0–22.0 | 1.35–1.70 | 0.10–0.80 | 0.20–0.25 |
| 2304 | S32304 | 0.030 | 1.00 | 2.50 | 0.040 | 0.040 | 21.5–24.5 | 3.0–5.5 | 0.05–0.60 | 0.05–0.20 |
| 2205 | S31803 / S32205 | 0.030 | 1.00 | 2.00 | 0.030 | 0.020 | 21.0–23.0 | 4.5–6.5 | 2.5–3.5 | 0.08–0.20 |
| 2507 | S32750 | 0.030 | 0.80 | 1.20 | 0.035 | 0.020 | 24.0–26.0 | 6.0–8.0 | 3.0–5.0 | 0.24–0.32 |
| S32760 | S32760 | 0.030 | 1.00 | 1.00 | 0.030 | 0.010 | 24.0–26.0 | 6.0–8.0 | 3.0–4.0 | 0.20–0.30 |
Note: Exact chemical composition requirements depend on the applicable ASTM, ASME, EN, JIS or GB/T standard and grade. The applicable purchase specification shall prevail.
For reference, Outokumpu lists typical compositions around Cr 22.4%, Ni 5.7%, Mo 3.1%, N 0.17% for 2205, and Cr 25%, Ni 7%, Mo 4%, N 0.27% for 2507.
| Grade | Yield Strength Rp0.2 Min. | Tensile Strength Rm Min. | Elongation A50 Min. |
|---|---|---|---|
| 2101 | ≥450 MPa* | ≥650 MPa* | ≥30% |
| 2304 | ≥400 MPa | ≥600 MPa | ≥25% |
| 2205 | ≥450 MPa | ≥655 MPa | ≥25% |
| 2507 | ≥550 MPa | ≥795 MPa | ≥15% |
| S32760 | ≥550 MPa | ≥750 MPa | ≥25% |
The 2205 and 2507 values above correspond to ASTM A240 minimum values reported by Outokumpu for plate, sheet and strip.
* Mechanical requirements for 2101 can vary with thickness and applicable specification.
| Grade | Strength | Corrosion Resistance | Typical Application |
|---|---|---|---|
| 2101 | High | Good | Storage tanks, structural components, pulp & paper |
| 2304 | High | Very Good | Chemical equipment, pressure vessels, heat exchangers |
| 2205 | Very High | Excellent | Oil & gas, chemical, marine, petrochemical |
| 2507 | Extremely High | Excellent / Very High | Offshore, seawater, desalination, subsea |
| S32760 | Extremely High | Excellent / Very High | Offshore, chemical processing, seawater systems |
Duplex stainless steel generally offers substantially higher yield strength than common 304/316 austenitic stainless steels, allowing potential material and weight reduction in suitable designs.
Good resistance to general corrosion, pitting corrosion and crevice corrosion, particularly in chloride-containing environments.
Duplex grades are especially valued for their resistance to chloride stress corrosion cracking (SCC) compared with conventional austenitic stainless steels.
Modern duplex grades offer good weldability when the appropriate welding procedure and heat input are controlled.
The combination of high yield strength and corrosion resistance makes duplex stainless steel suitable for demanding structural and process applications.
| Surface | Description | Typical Applications |
|---|---|---|
| 2B | Smooth cold rolled surface | General industrial applications |
| BA | Bright Annealed surface | Decorative and precision applications |
| No.1 | Hot rolled, annealed and pickled | Chemical equipment, pressure vessels |
| No.4 | Brushed / satin finish | Architectural and decorative applications |
| HL | Hairline finish | Architectural applications |
| Customized | Special surface according to requirement | Special industrial applications |
| Industry | Applications |
|---|---|
| Oil & Gas | Pipelines, valves, flanges, pressure equipment |
| Petrochemical | Process equipment, tanks, piping |
| Chemical Processing | Storage tanks, reactors, heat exchangers |
| Marine | Marine structures, seawater systems |
| Offshore | Offshore platforms, subsea components |
| Desalination | Desalination equipment, seawater piping |
| Pulp & Paper | Digesters, process tanks, piping |
| Heat Exchangers | Heat exchanger tubes and components |
| Pressure Vessels | Pressure vessels and storage tanks |
| Water Treatment | Water treatment and seawater equipment |
| Industrial Equipment | Pumps, shafts, valves, rotors and impellers |
These application areas are consistent with major duplex grade applications reported by Outokumpu, including chemical tankers, pulp & paper, oil & gas, desalination, offshore, heat exchangers and pressure vessels.
| Standard System | Typical Standards / Designations |
|---|---|
| ASTM | ASTM A240 / A240M |
| ASME | ASME SA240 / SA240M |
| AISI / UNS | S32101 / S32304 / S31803 / S32205 / S32750 / S32760 |
| EN | EN 10088-2 / EN 10028-7 |
| JIS | Applicable JIS Duplex Stainless Steel Standards |
| GB/T | Applicable GB/T Duplex Stainless Steel Standards |
| DIN | Applicable DIN Stainless Steel Standards |
| Product Category | Common HS Code Reference |
|---|---|
| Duplex Stainless Steel Coil | HS 7219 |
| Cold Rolled Duplex Stainless Steel Coil | HS 7219 |
| Hot Rolled Duplex Stainless Steel Coil | HS 7219 |
| Duplex Stainless Steel Strip ≤600 mm | HS 7220 |
| Duplex Stainless Steel Slit Coil | HS 7220 |
| Duplex Stainless Steel Strip Coil | HS 7220 |
Note: Final HS classification should be confirmed according to the product's width, thickness, form, production process, grade and destination-country customs tariff.
Duplex Stainless Steel Coil Manufacturer & Supplier
Baojing Steel supplies high-quality Duplex Stainless Steel Coils in 2101, 2304, 2205, 2507 and S32760 grades. Available in cold rolled and hot rolled conditions with customized thicknesses, widths and surface finishes. Duplex stainless steel combines high mechanical strength, excellent corrosion resistance and superior resistance to stress corrosion cracking, making it ideal for oil & gas, chemical processing, marine, offshore, desalination, heat exchangers, pressure vessels and industrial applications.
